Product advantages

1.Super low consumption, energy economized, high power rate
2.Amorphous Alloyed material can tremendously reduce the power consumption and loss. The motor with this material will discharge much less SO、 CO gases, which to a large extent decelerates the pollution and greenhouse effect.
3.Operating temperature stays low , insulation aging slow, transformer service life 's long
4.Wonderful overload capability, and excellent mechanical strength
5.Good Harmonic-bearing capability. When the amorphous core cross through the high-frequency flux, the motor can still work in a low core loss and low excitation current way. So that the core saturation problem can be avoided.
6.Benefit on investment returns quickly.

Operating conditions

1.Phase number: tree-phase
2.Voltage level: Primary side voltage:10kV Secondary side voltage: 0.4kV
3.Frequency: 50Hz
4.Connection symbol : Dyn11、Yyn0 or according to the specific requirements
5.Cooling method: self cooling or forced air cooling
6.Operating environment: altitude≤ 1000m, max relative humidity 100%, ambient temperature should below 40℃
7.Insulation endurance class: F
8.Winding temperature rise: 100K

Implementation of the standards

GB 1094.11-2007 GB 1094-1996 GB/T22072-2008 GT/T17211-1998
JB/T 10088-2004 GB 4208-1993 IEC726

Models and meaning
